Home > Products > Diamond Grinding Wheels > Isotropic Ceramic Ferrite Arc Magnet

Isotropic Ceramic  Ferrite Arc Magnet

  • Isotropic Ceramic  Ferrite Arc Magnet
  • Isotropic Ceramic  Ferrite Arc Magnet

Isotropic Ceramic Ferrite Arc Magnet

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,EXW,FCA,CPT,CIP
    Min. Order: 1 Piece/Pieces
    Delivery Time: 25 Days
    Packaging: Sealed plastic bag-White box-Foam box-Cartons-Pallet or Case
    Productivity: 60tons
    Brand: Honesun
    Transportation: Ocean,Land,Air,express
    Place of Origin: China,zhejiang
    Supply Ability: 60TONS PER MONTH
    Certificate: ISO9001:2001
    HS Code: 8505190090
    Port: NINGBO,Shanghai,Other Port

Basic Info

Model No.: HS-FM27

Product Description

Isotropic Ceramic Ferrite Arc Magnet-ferrite magnets are composed of ferric oxide, barium oxide, strontium oxide and other oxides. They are hard and brittle materials with +/-2% tolerance,

which require diamond wheels for grinding to the close tolerances.
Ferrite Magnets are also called Ceramic Magnets. Since the 1950s, hard ferrite(ceramic)magnets have been widely applied, compared with other permanent magnets, ferrite magnet is cheap. It is most suitable for most sensitive, but need not very high performance applications. As this is a non-metal magnets, it is the ideal magnets for applications that require non-rusty magnets in hum-it environment.

Grade Br HcB Hcj (BH)max
KGs mT kOe Ka/m kOe Ka/m MGOe Kj/m³
Y10T 2.00~2.35 200~235 1.57~2.01 125~160 2.64~3.52 210~280 0.81~1.19 6.5~9.5
Y25 3.60~4.00 360~400 1.70~2.20 135~175 1.76~2.51 140~200 2.80~3.50 22.5~28.0
Y30 3.70~4.00 370~400 2.20~2.64 175~210 2.26~2.77 180~220 3.30~3.77 26.0~30.0
Y30BH 3.80~4.00 380~400 2.80~3.46 223~275 2.85~3.65 227~290 3.40~4.10 27.0~32.5
Y33 4.00~4.30 400~430 2.76~3.14 220~250 2.83~3.20 225~255 3.96~4.40 31.5~35.0
Y35 4.00~4.20 400~420 2.20~2.70 175~222 2.26~2.80 180~241 3.80~4.20 30.0~33.0
Y35AH 400~410 4.00~4.10 2.60~2.8 200~225 2.7~2.90 210~230 3.90~4.10 31.0~33.0
Y36 430~450 4.30~4.50 3.10~280 240~275 3.14~3.42 250~270 4.40~4.80 35.0~38.0
Y38 440~460 4.40~4.60 3.58~3.83 285~305 3.69~3.89 294~310 4.60~5.10 36.6~40.6
Y40 440~460 4.40~4.60 4.15~4.45 330~354 4.27~4.52 340~360 4.70~5.20 37.6~41.8

138
300

Photobank

2


3

1.How fast can I get a reply?
You will receive our reply within 15 minutes during our work time 08:00-18:00(UTC-8).
2.Can I get free samples?
Free samples are available at Warehouse. However it may take minimum 7 days for production if your size is not on our stock list.
3.Are you able to offer best price?
Magnets are functional products,the cost depend on how strong the materials you need. We believe the most suitable is the best, therefore HONESUN keen to offer best prices to meet your targets.
4.Are you able to provide best quality?
At our company you receive products under guarantee of ISO9001systems.
5.What are your best lead time?
Immediately shipments are available for stock magnets. For fresh materials,we need 7-15 days for production.
6.How can you sure that my money is safe with you?
As an Alibaba Trade Assurance member, your funds are under protection of Alibaba group. Payments will not be released to vendor until buyer confirms receipt and good material of delivery.

Windy Wang

Honesun Industrial Co.,Limited

 Quality system is followed with ISO9001:2000, setting with test machine: BH curve, surface gauss, flux meter, salt spray facility, PCT for weight loss and etc.With team well experienced in more than 10 years, we focus on quality controlling and service, remaining competitive price, to help our customer to be successful on their stage.Sincerely hope we can establish a good and long-time relationship.Honesun Industrial Co.,Limited
